Solenoid replacement coil (9V / 24V)
Interchangeable solenoid coil for Poelsan solenoid valves (SV100/SV151/SV201), in 9V (latching) and 24V.
Description
Interchangeable solenoid coil for the Poelsan SV-series solenoid valves (common thread, suitable for 1″, 1½″ and 2″). Available as a 9V version (latching, pulse-controlled) and a 24V version.
Features
- Suitable for solenoid valves SV100 / SV151 / SV201 (common thread)
- Available in 9V (latching) and 24V
- Easy replacement
Item numbers
| Item no. | Designation | Pack | Box qty |
|---|---|---|---|
| SV9VB | Solenoid coil 9V | 5 | 100 |
| SV24VB | Solenoid coil 24V | 5 | 100 |
Electrical data
| Voltage | Operating voltage | Inrush current | Holding current | Internal resistance |
|---|---|---|---|---|
| 9V (latching) | 6–11 V DC | pulse max. 50 ms | – | 7 Ω |
| 24 V AC (60 Hz) | 19–28 V AC | 370 mA | 230 mA | 27 Ω |
| 24 V AC (50 Hz) | 19–28 V AC | 400 mA | 250 mA | 27 Ω |
Additional information
| Einsatzbereich | Bewässerung |
|---|---|
| Spannung | 9V / 24V |
| Typ | Ersatzspule |
